| 1. Genset main specifications | ||
| Genset model | OW500GF | |
| Rated power(KW/KVA) | 500/625 | |
| Standby power(KW/KVA) | 560/700 | |
| Rated Current/Max. Current(A) | 902 | |
| Reference sizes (L*W*H) | 3850*1600*2180mm | |
| Reference weight | 4950kg | |
| Rated output voltage(V) | 400/230; 3 phase 4 wire | |
| Frequency (Hz) | 50 | |
| Rated speed(rpm) | 1500 | |
| Rated power factor | 0.8 | |
| Exciting mode | Brushless self-excitation | |
| Starting mode | DC24V motor starting | |
| Speed regulation | Electronic speed regulation | |
| Cooling mode | Closed water cooling | |
| 2. Gensent main performance index | ||
| Frequency drop (%) | 0-5 | |
| Steady-state frequency band(%) | ≤1.5 | |
| Transient frequency deviation | 100% sudden power reduction(%) | ≤+12 |
| Sudden power boost(%) | ≤-20 | |
| Frequency recovery time (S) | ≤5 | |
| Relative frequency tolerance band(%) | 2 | |
| Steady voltage deviation(%) | ≤±2.5 | |
| Transient Voltage deviation | 100% sudden power reduction(%) | ≤+25 |
| Sudden power boost(%) | ≤-20 | |
| Voltage recovery time (S) | ≤6 | |
| 3. Engine technical specs | ||
| Model | Weichai 6M33D633E200 | |
| Rated power(KW/KVA) | 575/719 | |
| Max.power(KW/KVA) | 633/791.25 | |
| Rated speed(rpm) | 1500 | |
| Type | Water cooled, in-line, four stroke | |
| Intake type | Turbocharging，Air-air intercooler | |
| Cylinder No. | 6.L | |
| Compression ratio | 15 ：1 | |
| Trip * Bore | 150*185mm | |
| Oil capacity | 60 L（CF grade or above，The specific model is selected according to the ambient temperature） | |
| Displacement | 19.6 L | |
| Anti Freezing solution | 135L（recommend to use -35℃，The specific model is selected according to the ambient temperature） | |
| 4.Alternator technical specs | ||
| Model | HC534FS | |
| Rated power(KW) | 500/625 | |
| Voltage(V) | 400/230 | |
| Frequency(Hz) | 50 | |
| Insulation class | H class | |
| Protection class | IP22 | |
| Phase & wires | 3 phase 4 wire | |
| Voltage regulator | AVR | |
| Exciting mode | Brushless self-excitation | |
| 5. Control system specs | ||
| Model | HGM6120NC | |
| Display | LCD（132x64） | |
| Controller language | Chinese & English & Spanish & Russian & Others | |
| Alarm | Ø Speed is too high/too low Ø The battery voltage is too low or too high Ø Start and stop failed Ø Charging failure Ø Overcurrent Ø Unit voltage is too low/too high Ø Low oil pressure Ø Emergency stop Ø Excessive engine temperature Ø Overload | |
| Monitor display | Ø Unit voltage (phase-phase/Phase-line) Ø Engine oil pressure (pounds per square inch - bar) Ø Current(L1,L2,L3) Ø Engine temperature (°C and °F) Ø Unit frequency (Hz) Ø Factory battery voltage Ø Engine running hour meter Ø Unit kVA, KWH Ø Unit power as a percentage of rated power Ø Unit Cos (σ) | |
| Configuration Details | |||
| Item | Model | Quantity | Remark |
| Engine | Weichai 6M33D633E200 | 1 | installed |
| Alternator | HC534FS | 1 | installed |
| Radiator | 50℃ original water tank | 1 | installed |
| Breaker | Chint 1000A MCCB | 1 | installed |
| Control System | HGM6120 | 1 | installed |
| Remote monitoring module Модуль удаленного мониторинга | PC + WIFI monitor | 1 | installed |
| Chassis | 800L diesel oil chassis tank | 1 | installed |
| Fuel filter | original | 1 | installed |
| Oil filter | original | 1 | installed |
| Air filter | original | 1 | installed |
| Storage battery | Maintenance-free battery | 1 | installed |
| battery cable | Pure copper battery wire | 1 | installed |
| Absorber | original | 1 | installed |
| Cylinder liner water preheater | 4kW 220V | 1 | installed |
| Independent ATS cabinet | 1000A Dual power switching cabinet | 1 | Independent |
| Bellows & silencer | original | 1 | installed |
| Accessories and materials | Generator Unit manual; Engine manual; Alternator manual;Certificate of qualification; tools, etc | 1 | Included |
