OWELL 15kw electric generator vertical axis wind turbine
Features:
l Direct-drive permanent magnet ironless synchronous generator
l Stall design of blade over wind speed
l Mechanical automatic brake
l Electronic unloading and hydraulic brake protection
l Equipped with anemometer
l pwm unloading
l plc controller, equipped with hmi real-time screen monitoring, can download historical data.
Support customization
OWELL 15kw electric generator vertical axis wind turbine
Features:
l Direct-drive permanent magnet ironless synchronous generator
l Stall design of blade over wind speed
l Mechanical automatic brake
l Electronic unloading and hydraulic brake protection
l Equipped with anemometer
l pwm unloading
l plc controller, equipped with hmi real-time screen monitoring, can download historical data.
Support customization
The OW-15kWH wind turbine uses a direct-drive permanent magnet synchronous generator with a generator starting torque of 7-10Nm and can be started at a wind speed of 2.5m / s. The maximum output power of the fan can reach 18kW, and the generator complies with IEC 60034-1 Medium S1 continuous working system requirements. It can still have stable power output at high wind speeds. This model has 3 safety protection systems: stall, electronic unloading, and hydraulic brake, making the system work more safe and reliable.
OVERVIEW
| Item | OWELL-15KWH |
| Rated Power | 15KW |
| Max Power | 18KW |
| Rated Voltage | Customized |
| Rated speed | 80 RPM |
| Start wind speed | 2.5m/s |
| Rated wind speed | 12m/s |
| Safety wind speed | 45m/s |
| Turbine Weight | 1050KG |
| Wheel diameter | 4.3m |
| Wheel height | 6.8m |
| Blade quantity | 3/4/5 pieces |
| Blade materials | FRP+Steel Frame |
| Turbine materials | Aluminium Alloy |
| Braking system | Electromagnetic brake/mechanical brake(customerized) |
| Hydraulic brake | Active brake, electric outage brake |
| Alternator | Three-phase AC Disc Magnetic Levitation Alterntaor |
| Control system | Electromagnetic/The wind Angle automatically |
| Yaw method | Speed self-protection, manual hydraulic brake, electronic brake |
| lubrication mode | Self-lubrication |
| Insulation Class | H |
| Design Level | IEC class III |
| Noise | ≤55dB |
| Protection Class | IP54 |
| Working temperature | -40℃-80℃ |
| Design life | 15 years |
| Controller unit | PLC |
| Interface | HMI |
| Electronic unloading | 20KW brake resistance box |
very great product and professional team !
