Series 140 engine is a high-performance, high-speed engine with full intellectual property rights developed by Jichai and AVL, featuring high pressurization, low energy consumption, high reliability, and long service life. It can meet the TIER2 and European Ⅲ emission standards, Widely used in oil vehicle drilling rigs, oil specials, wellsite generator sets, mobile power stations or backup power sources, construction machinery, trucks, and other fields. Each technical index achieves the international advanced level.
Engine model | Cylinders & Arrangement | Cylinder Bore,mm | Piston stroke,mm | Rated power ,kW | RPM,r/min | Total piston displacement,L | Heat consumption ratekJ/kW.h | Lub. oil consumption Rateg/kW.h | Start method |
JC15D/T | 6 cylinders, in-line | 140 | 165 | 350 | 1500 | 15.24 | ≤10000 | ≤0.35 | Electric start |
280 | 1200 |
420 | 1800 |
Genset Model | Engine model | Alternator Model | Power kW | Voltage V | RPM,r/min | Frequency Hz | Power factor | Dimension mm | Weight kg |
300GF30-T | JC15D/T | XN5C series | 300 | 400V/6300V/10500V | 1500 | 50 | 0.8 | 3701×1345×1701 | 3900 |
240GF-T | 240 | 480/13800 | 1200 | 60 |
370GF-T | 370 | 480/13800 | 1800 | 60 |
